General Information

ADI Part Number

2.0C-H6M-D1

Brand Name

Avigilon Unity

Manufacturer

Motorola Solutions, Inc.

Manufacturer Part Number

2.0C-H6M-D1

Product Line

H6M

Product Model

2.0C-H6M-D1-IR

Product Name

H6 Mini Dome Camera

Product Series

H6M

Product Type

Dome Cameras

weight

166 g

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

2MP

Field of View

Horizontal: 108°, Vertical: 61°

Lens Type

Fixed

Maximum Aperture

f/2

Maximum Frame Rate

30 fps

Minimum Focal Length

2.9mm

Night Vision

Yes

Night Vision Type

Infrared

Wide Dynamic Range

Yes

Camera

Night Vision Distance

10 m

Certifications

RoHS Compliant

Compliant

TAA Compliant

No

Display & Graphics

Maximum Video Resolution

1920 x 1080

Environmental Conditions

Maximum Operating Temperature

50°C

Minimum Operating Temperature

-10°C

Operating Humidity

95%

Exposure

Longest Shutter Speed

1/7.5 Second

Minimum Illumination

0.003 lux

Shortest Shutter Speed

1/8000 Second

Interfaces/Ports

HDMI

No

Network (RJ-45)

Yes

Lens

Focal Length

2.9 mm

Lens Included

Yes

Maximum Focal Length

2.90 mm

Physical Characteristics

Color

White

Form Factor

Mini Dome

Height

63.5 mm

Width

73.7 mm

Product Information

Length

73.7 mm

Mount Type

Ceiling Mount, Pendant Mount, Surface Mount

Storage

Recording Formats

Full HD

Storage Type

Memory Card

Warranty

Limited Warranty

5-Year

Miscellaneous

Environmental Certification

RoHS

Environmentally Friendly

Yes

Features

3D Noise Reduction, Automatic White Balance, Back Light Compensation (BLC), Day/Night, HTTPS Encryption, Motion Detection, SD Card Local Storage, Tamper Detection, Wide Dynamic Range

Indoor/Outdoor

Indoor

Avigilon Unity H6 H6M Series IP Mini Dome Camera, WDR 2MP 2.9mm Fixed Lens, White
