General Information

ADI Part Number

TL-SG1016PE

Brand Name

TP-Link

Manufacturer

TP-Link

Manufacturer Part Number

TL-SG1016PE

Product Model

TL-SG1016PE

Product Name

TL-SG1016PE 16-Port Gigabit Easy Smart PoE Switch with 8-Port PoE+

Product Type

Switch

Technical Information

Media Type Supported

Twisted Pair

Power Consumption

131.4W

Certifications

RoHS Compliant

Compliant

Interfaces/Ports

Modular

No

Network (RJ-45)

Yes

Total Number of Network Ports

16

Uplink Port

No

Management & Protocols

Manageable

Yes

Media & Performance

Network Technology

1000Base-T, 100Base-TX, 10Base-T

Network & Communication

Ethernet Technology

Gigabit Ethernet

Layer Supported

2

Networking Standards

IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

Physical Characteristics

Compatible Rack Unit

1U

Depth

180 mm

Height

44 mm

Width

294 mm

Power Description

PoE (RJ-45) Port

Yes

PoE Budget

110W

Power Source

AC

Product Information

Mount Type

Desktop, Rack Mount

Warranty

Limited Warranty

1-Year

Miscellaneous

Environmental Certification

RoHS

Package Contents

TL-SG1016PE
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet

TP-Link TL-SG1016PE 16-Port Gigabit Easy Smart Switch with 8-Port PoE+
