General Information

ADI Part Number

IPHDW3241TZAS27135

Brand Name

Dahua Technology

Manufacturer

Zhejiang Dahua Technology Co., Ltd.

Manufacturer Part Number

IPC-HDW3241T-ZAS 2.7-13.5mm

Product Line

WizSense

Product Model

IPC-HDW3241T-ZAS

Product Name

2MP IR Vari-focal Eyeball WizSense Network Camera

Product Series

WizSense

Product Type

Turret Cameras

weight

685 g

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

2MP

Field of View

Horizontal: 109°-30° Vertical: 56° -17° Diagonal: 137° -35°

Lens Mount Type

M14

Lens Type

Zoom

Maximum Aperture

f/1.5

Maximum Frame Rate

30 fps

Minimum Focal Length

2.7mm

Night Vision

Yes

Night Vision Type

Colour

Number of IR LEDs

2

Optical Zoom

5x

Video Formats

H.264, H.265, MJPEG

Video Resolution

1280 x 720

Wide Dynamic Range

Yes

Camera

Image Sensor Type

CMOS

Night Vision Distance

40 m

Certifications

Ingress Protection Rating

IP67

RoHS Compliant

Compliant

Display & Graphics

Maximum Video Resolution

1920 x 1080

Environmental Conditions

Maximum Operating Temperature

60°C

Minimum Operating Temperature

-30°C

Operating Humidity

0.95

Exposure

Longest Shutter Speed

1/3 Second

Shortest Shutter Speed

1/100000 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Focal Length

2.7-13.5mm

Lens Included

Yes

Maximum Focal Length

13.50 mm

Network & Communication

Remote Management

Yes

Physical Characteristics

Color

White

Durability

Dust Proof

Form Factor

Eyeball

Height

75.9 mm

Width

79 mm

Power Description

Input Voltage

12V DC

Product Information

Length

244.1 mm

Storage

Recording Formats

HD

Storage Type

Memory Card

Warranty

Limited Warranty

5-Year

Miscellaneous

Features

3D Noise Reduction, Back Light Compensation (BLC), Built-in Card Reader, Built-in HLC, Day/Night, Motion Detection, Privacy Masking, Region of Interest

Impact Protection Rating

IK10

Indoor/Outdoor

Outdoor

Dahua IPC-HDW3241T-ZAS WizSense, IP67 2MP 2.7-13.5mm Motorized Varifocal Lens, IR 40M IP Turret Camera, White
