General Information

ADI Part Number

TX26E4

Brand Name

CDVI

Manufacturer

CDVI

Manufacturer Part Number

TX26-E4

Packaged Quantity

1

Product Model

TX26-E4

Product Name

TX26-E range - Channel transmitter

Product Series

TX26

Product Type

Transmitter

weight

0.03 kg

Technical Information

Channel Frequency

433.92 MHz

Maximum Operating Distance

250 m

Number of Buttons

4

Number of Channels

4

Wireless Technology

Radio Frequency

Battery Information

Battery Size Supported

L12028

Number of Batteries Supported

1

Certifications

CE Marking

Yes

RoHS Compliant

Compliant

TAA Compliant

No

Physical Characteristics

Application/Usage

Commercial, Garage Door, Gate, Industrial, Public Building, Roller Shutter

Color

Orange, White

Depth

16 mm

Form Factor

Wall Mount

Height

81 mm

Width

46 mm

Power Description

Input Voltage

12V

Power Source

Battery

Remote Control

Battery Included

Yes

Warranty

Limited Warranty

10-Year

Miscellaneous

Additional Information

Modulation: AM/ASK
Encoding: KeeLoq® hopping code

Compatibility

CDVI Rolling Code Receiver

Features

Compatible with CDVI 433.92MHz receivers, Four trigger buttons, Handheld transmitter, KeeLoq hopping code

Package Contents

4-channel Hand-held Transmitter
12V (L12028 Battery)
