General Information

ADI Part Number

TI-PG162

Brand Name

TRENDnet

Manufacturer

TRENDnet

Manufacturer Part Number

TI-PG162

Product Line

Industrial

Product Model

TI-PG162

Product Name

16-Port Industrial Gigabit PoE

Product Type

Ethernet Switch

Technical Information

Media Type Supported

Optical Fiber, Twisted Pair

Power Consumption

13W

Certifications

RoHS Compliant

Compliant

TAA Compliant

Yes

I/O Expansions

Expansion Slot Type

SFP (mini-GBIC)

Number of SFP Slots

2

Number of SFP+ Slots

2

Number of Total Expansion Slots

2

Interfaces/Ports

Modular

Yes

Total Number of Network Ports

16

Management & Protocols

Manageable

No

Media & Performance

Network Technology

1000Base-FX, 1000Base-T

Network & Communication

Ethernet Technology

Gigabit Ethernet

Layer Supported

2

Networking Standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Physical Characteristics

Depth

203.2 mm

Form Factor

DIN Rail Mount, Wall Mount

Height

76.2 mm

Material

Metal

Width

152.4 mm

Power Description

Frequency

50 Hz|60 Hz

Input Voltage

100V AC, 240V AC

Plug/Connector Type

Terminal Block

PoE Budget

240W

Power Source

Power Supply

Redundant Power Supply

Yes

Product Information

Length

155 mm

Warranty

Limited Warranty

Lifetime Warranty

Miscellaneous

Environmental Certification

CE, Freefall (IEC 60068-2-32), MET, Shock (IEC 60068-2-27), Vibration (IEC 60068-2-6)

Environmentally Friendly

Yes

Features

14 x Gigabit PoE ports, 2 x Gigabit SFP slots, 240W PoE power budget, 32Gbps switching capacity, Alarm output triggered by power failure, Hardened IP30 rated metal switch, Includes DIN-Rail mount and wall mount brackets, Multiple inputs provide redundant power with overload current protection, Power supply sold separately (model: TI-S48048), Wide operating temperature range of -40 to 75 deg C (-40 to 167 deg F)

Package Contents

TI-PG162
Quick Installation Guide
Removable terminal block
DIN-rail and wall mount kit

TRENDnet TI-PG162 16-Port Industrial Gigabit PoE+ DIN-Rail Switch
