Home /
Brands /
CDVI /
CDVI K2 Krypto Bluetooth Mullion Proximity Card Reader
Brand:
CDVI
ADI #:K2
Model #: K2
Name: CDVI K2 Krypto Bluetooth Mullion Proximity Card Reader
Easy to use and fully secure MIFARE® DESFire® reader
End-to-end encryption with the A22K controller and compatible credentials
Secure CDVI protocol using diversified key authentication
Product Overview
General Information
null
Main Features
Easy to use and fully secure MIFARE® DESFire® reader
End-to-end encryption with the A22K controller and compatible credentials
Secure CDVI protocol using diversified key authentication
Built-in Bluetooth for use with Mobile-PASS smartphone credentials
IP65 and IK10 rated - a robust solution
Information
Category : Access Control, Proximity Readers, Keypads & Readers, Products
EAN Code : 3662211018273
Specifications
General Information
ADI Part Number
K2
Brand Name
CDVI
Manufacturer
CDVI Group
Manufacturer Part Number
K2
Packaged Quantity
1
Product Line
Krypto
Product Model
K2
Product Name
Krypto DesFIRE EV2 RS485 Reader
Product Series
K SERIES
Product Type
Card Reader Access Device
Technical Information
Bluetooth
Yes
Identification Method
Proximity
Impact Protection (IK) Rating
IK09
Ingress Protection (IP) Rating
IP65
Number of Users
10000
Operating Range
5 cm
Operating Range (mm)
100
Wireless LAN
No
Interfaces/Ports
Network (RJ-45)
No
Serial
Yes
Physical Characteristics
Application/Usage
Access Control System, College, Commercial, Door, Hospital, Public Building, School, Small Business
Colour
Black
Depth
21.5 mm
Form Factor
Surface Mount
Height
126 mm
Width
46 mm
Power Description
Input Voltage
12V DC
Input Voltage (V DC)
12
Miscellaneous
Environmentally Friendly
Yes
