General Information

ADI Part Number

DGS-1100-24V2

Brand Name

D-Link

Manufacturer

D-Link

Manufacturer Part Number

DGS-1100-24V2

Product Model

DGS-1100-24V2

Product Name

DGS-1100 Series Gigabit Smart Managed Switches

Product Series

DGS-1100 (V2)

Product Type

Switch and Bridge

weight

1.32 kg

Technical Information

Media Type Supported

Twisted Pair

Power Consumption

15.9W

Certifications

RoHS Compliant

Compliant

TAA Compliant

No

Interfaces/Ports

Total Number of Network Ports

24

Management & Protocols

Manageable

Yes

Media & Performance

Network Technology

1000Base-T

Network & Communication

Ethernet Technology

Gigabit Ethernet

Layer Supported

2

Networking Standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u

Physical Characteristics

Compatible Rack Unit

1U

Depth

180 mm

Form Factor

Desktop, Rack-mountable

Height

44 mm

Material

Metal

Width

280 mm

Power Description

Input Voltage

100-240V AC

PoE Budget

370W

Power Source

Power Supply

Warranty

Limited Warranty

Lifetime Warranty

Miscellaneous

Environmental Certification

RoHS

Environmentally Friendly

Yes

Features

Free centralised management with Nuclias Connect, Limited-Lifetime Warranty after registration, PoE options up to 370W power budget, Simple Layer 2 Management, Web-based User Interface

D-Link DGS-1100-24V2 24-Port Gigabit Smart Managed Switch, Fanless
