General Information

ADI Part Number

40C-H5PRO-B

Brand Name

Avigilon Unity

Manufacturer

Motorola Solutions, Inc.

Manufacturer Part Number

40C-H5PRO-B

Product Line

H5 Pro

Product Model

40C-H5PRO-B

Product Name

H5 PRO CAMERA

Product Series

H5 Pro

Product Type

Box Cameras

weight

500 g

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

40MP

Lens Type

Fixed

Maximum Aperture

f/1.4

Maximum Frame Rate

10 fps

Minimum Focal Length

43.3mm

Night Vision

Yes

Video Formats

H.264, H.265, MJPEG

Video Resolution

1280 x 720

Wide Dynamic Range

Yes

Camera

Image Sensor Type

CMOS

Certifications

Ingress Protection Rating

IP66

RoHS Compliant

Compliant

TAA Compliant

No

Display & Graphics

Maximum Video Resolution

2688 x 1520

Environmental Conditions

Maximum Operating Temperature

60°C

Minimum Operating Temperature

-25°C

Operating Humidity

95%

Exposure

Longest Shutter Speed

1/7.5 Second

Minimum Illumination

0.04 lux

Shortest Shutter Speed

1/8000 Second

Interfaces/Ports

HDMI

No

Network (RJ-45)

Yes

Lens

Focal Length

43.3 mm

Lens Included

Yes

Maximum Focal Length

43.30 mm

Network & Communication

Remote Management

Yes

Physical Characteristics

Color

Black

Form Factor

Box Mount

Height

82 mm

Width

87 mm

Power Description

Input Voltage

12V DC, 24V AC

Product Information

Length

142 mm

Mount Type

Bottom Mount, Top Mount

Storage

Recording Formats

HD

Storage Type

Memory Card

Miscellaneous

Environmental Certification

RoHS, WEEE

Environmentally Friendly

Yes

Features

3D Digital Noise Reduction, Audio Compression, Automatic White Balance, Back Light Compensation (BLC), Face Detection, Motion Detection, Motion Tracking, Privacy Protection, Video Content Analytics, Wide Dynamic Range

Indoor/Outdoor

Indoor, Outdoor

Avigilon Unity 40C-H5PRO-B H5 Pro Series, WDR IP66 40MP, IP Box Camera, Black
