General Information

ADI Part Number

32C-H5A-4MH

Brand Name

Avigilon Unity

Manufacturer

Motorola Solutions, Inc.

Manufacturer Part Number

32C-H5A-4MH

Product Line

H5A

Product Model

32C-H5A-4MH

Product Name

H5A MULTISENSOR CAMERA

Product Series

H5A

Product Type

Network Camera

weight

1190 g

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

8MP

Field of View

Horizontal: 53°-97°, Vertical: 29°-50°

Lens Type

Fixed

Maximum Aperture

f/1.9

Maximum Frame Rate

30 fps

Minimum Focal Length

3.3mm

Night Vision

Yes

Night Vision Type

Infrared

Video Formats

H.264, H.265, MJPEG

Video Resolution

1280 x 720

Wide Dynamic Range

Yes

Camera

Image Sensor Type

CMOS

Night Vision Distance

30 m

Certifications

Ingress Protection Rating

IP66, IP67

RoHS Compliant

Compliant

TAA Compliant

No

Environmental Conditions

Maximum Operating Temperature

60°C

Minimum Operating Temperature

-40°C

Operating Humidity

0-95%

Exposure

Longest Shutter Speed

1/7.5 Second

Minimum Illumination

0.016 lux

Shortest Shutter Speed

1/8000 Second

Interfaces/Ports

HDMI

No

Lens

Focal Length

3.3-5.7mm

Lens Included

Yes

Maximum Focal Length

5.70 mm

Network & Communication

Remote Management

Yes

Physical Characteristics

Color

White

Durability

Corrosion Resistant, Dust Resistant, Impact Resistant, Water Resistant

Height

222 mm

Power Description

Input Voltage

24V AC

Product Information

Mount Type

Pendant Mount

Storage

Recording Formats

HD

Storage Type

Memory Card

Miscellaneous

Environmental Certification

RoHS

Environmentally Friendly

Yes

Impact Protection Rating

IK10

Indoor/Outdoor

Outdoor

Avigilon Unity 32C-H5A-4MH 32MP Multisensor Camera, 3.3-5.7mm Varifocal Lens, WDR, 360° Max Field of View, White
