General Information

ADI Part Number

XNO-6123RRW

Brand Name

Hanwha Vision

Manufacturer

Hanwha Group

Manufacturer Part Number

XNO-6123R/RW

Product Model

XNO-6123R/RW

Product Name

2MP IR Bullet Camera with RoadWatch ANPR

Product Series

X series

Product Type

Network Camera

weight

2.30 kg

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

2MP

Field of View

H: 55°(Wide)~5°(Tele) / V: 33°(Wide)~3°(Tele) / D: 62°(Wide)~6°(Tele)

Lens Type

Varifocal

Maximum Aperture

f/1.6

Maximum Frame Rate

120 fps

Minimum Focal Length

5.2mm

Night Vision

Yes

Night Vision Type

Infrared

Number of IR LEDs

30

Optical Zoom

12x

Video Formats

H.264, H.265, MJPEG

Video Resolution

1280 x 720

Camera

Image Sensor Type

CMOS

Night Vision Distance

90 m

Certifications

Ingress Protection Rating

IP66, IP67

RoHS Compliant

Compliant

TAA Compliant

No

Display & Graphics

Maximum Video Resolution

1920 x 1080

Environmental Conditions

Maximum Operating Temperature

60°C

Minimum Operating Temperature

-40°C

Operating Humidity

0.95

Exposure

Longest Shutter Speed

2 Second

Shortest Shutter Speed

1/12000 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Lens Included

Yes

Maximum Focal Length

62.40 mm

Minimum Aperture

f/3

Network & Communication

Remote Management

Yes

Physical Characteristics

Color

White

Form Factor

Bullet

Power Description

Input Voltage

12V DC

Product Information

Diameter

93.4 mm

Mount Type

Backbox Mount, Conduit Mount, Gang Box Mount

Storage

Recording Formats

Full HD

Storage Type

Memory Card

Video

Analog Video Signal Format

CVBS

Warranty

Limited Warranty

5-Year

Miscellaneous

Features

Back Light Compensation (BLC), Day/Night, Defog, Digital Image Stabilization, Digital Noise Reduction, Gain Control, Highlight Compensation (HLC), Motion Detection, Privacy Masking, White Balance, Wide Dynamic Range

Impact Protection Rating

IK10

Indoor/Outdoor

Outdoor

Package Contents

2MP IR Bullet Camera with RoadWatch ANPR
Backbox
RoadWatch ANPR

Hanwha XNO-6123R/RW 2MP IR Bullet Camera with RoadWatch ANPR, 5.2-62.4mm Varifocal Lens, IP66 IP67 IK10, White
