General Information

ADI Part Number

TI-PG80

Brand Name

TRENDnet

Manufacturer

TRENDnet

Manufacturer Part Number

TI-PG80

Product Line

Industrial

Product Model

TI-PG80

Product Name

8-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch

Product Type

Ethernet Switch

weight

554 g

Technical Information

Media Type Supported

Twisted Pair

Power Consumption

5.3W

Certifications

NDAA Compliant

Yes

RoHS Compliant

Compliant

TAA Compliant

Yes

Interfaces/Ports

Modular

No

Total Number of Network Ports

8

Uplink Port

No

Management & Protocols

Manageable

No

Media & Performance

Network Technology

1000Base-T

Network & Communication

Ethernet Technology

Gigabit Ethernet

Layer Supported

2

Networking Standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x

Physical Characteristics

Depth

36 mm

Form Factor

Rail Mount, Wall Mount

Height

143 mm

Material

Metal

Width

104 mm

Power Description

Input Voltage

24V DC, 56V DC

Plug/Connector Type

Terminal Block

Power Source

Power Supply

Redundant Power Supply

Yes

Warranty

Limited Warranty

Lifetime Warranty

Miscellaneous

Country of Origin

TW

Environmental Certification

CE, Freefall (IEC 60068-2-32), Shock (IEC 60068-2-27), Vibration

Features

16Gbps switching capacity, 8 x Gigabit PoE ports, Dual 24 - 56V DC power inputs for redundancy, Hardened IP30 rated metal switch, Includes DIN-rail and wall mounts, Operating temperature range of -40 to 75 deg C (-40 to 167 deg F), PoE power budget 120W at 24V - 200W at 48V, Power supply sold separately (models: TI-S15052, TI-S24052, TI-S12024, TI-S24048)

Package Contents

TI-PG80B
Quick Installation Guide
Removable terminal block
DIN-Rail and wall mount kit

TRENDnet TI-PG80 8-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch, 16Gbps
