General Information

ADI Part Number

TV-IP1515PI

Brand Name

TRENDnet

Manufacturer

TRENDnet

Manufacturer Part Number

TV-IP1515PI

Product Model

TV-IP1515PI

Product Name

2MP Vandal-Resistant Network IR Flateye Dome

Product Type

Network Camera

weight

295 g

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

2MP

Field of View

H: 94.8° / V: 49.3° / D: 114.3°

Lens Type

Fixed

Maximum Aperture

f/2.0

Maximum Frame Rate

30 fps

Minimum Focal Length

3.6mm

Night Vision

Yes

Night Vision Type

Colour

Wide Dynamic Range

Yes

Camera

Night Vision Distance

15 m

Certifications

Ingress Protection Rating

IP66

RoHS Compliant

Compliant

TAA Compliant

Yes

Display & Graphics

Maximum Video Resolution

1920 x 1080

Environmental Conditions

Maximum Operating Temperature

55°C

Minimum Operating Temperature

-30°C

Operating Humidity

95%

Exposure

Longest Shutter Speed

1/5 Second

Minimum Illumination

0.02 lux

Shortest Shutter Speed

1/12000 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Focal Length

3.6 mm

Lens Included

Yes

Maximum Focal Length

3.60 mm

Physical Characteristics

Color

White

Form Factor

Dome

Power Description

Input Voltage

100V AC, 240V AC

Storage

Recording Formats

Full HD

Storage Type

Memory Card

Warranty

Limited Warranty

3-Year

Miscellaneous

Features

Alarm Triggering, Automatic White Balance, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, Wide Dynamic Range

Indoor/Outdoor

Outdoor

TRENDnet TV-IP1515PI 5MP Fixed Turret Network Camera, H.265 WDR PoE 30 m IR IP66, White
